SchedulerTimerDispatchCleanup Class Reference

#include <SchedulerTimerDispatchCleanup.h>

Collaboration diagram for SchedulerTimerDispatchCleanup:

Public Member Functions
	SchedulerTimerDispatchCleanup (SchedulerTimerHandlerSlot::DispatchGuard &dispatch)

Private Member Functions
	SchedulerTimerDispatchCleanup (const SchedulerTimerDispatchCleanup &)
SchedulerTimerDispatchCleanup &	operator= (const SchedulerTimerDispatchCleanup &)
void	release ()

Static Private Member Functions
static void	abandon (void *context)

Private Attributes
SchedulerTimerHandlerSlot::DispatchGuard &	m_Dispatch
Thread *	m_Thread
AtomicStateCleanupRecord	m_Cleanup
bool	m_Active

Detailed Description

Binds one scheduler-timer admission to the current Thread state.

A scheduler callback may switch away and later have its suspended hard frame abandoned. Thread teardown retires this record before discarding the stack, so the handler slot cannot retain an admission whose destructor will never run.

Definition at line 25 of file SchedulerTimerDispatchCleanup.h.

Constructor & Destructor Documentation

SchedulerTimerDispatchCleanup()

SchedulerTimerDispatchCleanup::SchedulerTimerDispatchCleanup ( SchedulerTimerHandlerSlot::DispatchGuard &  dispatch )

explicit

Definition at line 29 of file SchedulerTimer.cc.

~SchedulerTimerDispatchCleanup()

SchedulerTimerDispatchCleanup::~SchedulerTimerDispatchCleanup

(

)

Definition at line 45 of file SchedulerTimer.cc.

Member Function Documentation

abandon()

void SchedulerTimerDispatchCleanup::abandon ( void *  context )

staticprivate

Definition at line 56 of file SchedulerTimer.cc.

release()

void SchedulerTimerDispatchCleanup::release ( )

private

Definition at line 64 of file SchedulerTimer.cc.

Member Data Documentation

m_Active

bool SchedulerTimerDispatchCleanup::m_Active

private

Definition at line 40 of file SchedulerTimerDispatchCleanup.h.

m_Cleanup

AtomicStateCleanupRecord SchedulerTimerDispatchCleanup::m_Cleanup

private

Definition at line 39 of file SchedulerTimerDispatchCleanup.h.

m_Dispatch

SchedulerTimerHandlerSlot::DispatchGuard& SchedulerTimerDispatchCleanup::m_Dispatch

private

Definition at line 37 of file SchedulerTimerDispatchCleanup.h.

m_Thread

Thread* SchedulerTimerDispatchCleanup::m_Thread

private

Definition at line 38 of file SchedulerTimerDispatchCleanup.h.

---

The documentation for this class was generated from the following files:

• SchedulerTimerDispatchCleanup.h
• SchedulerTimer.cc
