Inheritance diagram for Ps2Controller:

Collaboration diagram for Ps2Controller:

Public Member Functions
	Ps2Controller (Controller *pDev)

virtual void	getName (String &str)

virtual void	dump (String &str)

void	initialise ()

void	sendCommand (uint8_t command)
	Send a command to the PS/2 controller that has no response or data.

void	sendCommand (uint8_t command, uint8_t data)

uint8_t	sendCommandWithResponse (uint8_t command)
	Send a command to the PS/2 controller and report its response. More...

uint8_t	sendCommandWithResponse (uint8_t command, uint8_t data)

void	writeFirstPort (uint8_t byte)
	Send a byte to the first port of the PS/2 controller.

EXPORTED_PUBLIC void	writeSecondPort (uint8_t byte)
	Send a byte to the second port of the PS/2 controller.

bool	hasSecondPort () const
	Reports whether this PS/2 controller has two ports.

EXPORTED_PUBLIC void	setIrqEnable (bool firstEnabled, bool secondEnabled)
	Enables/disables IRQs for the first or second ports.

uint8_t	readByte ()
	Reads a single byte from the PS/2 controller by polling.

uint8_t	readByteNonBlock ()

bool	readFirstPort (uint8_t &byte, bool block=true)
	Reads a single byte from the first port.

EXPORTED_PUBLIC bool	readSecondPort (uint8_t &byte, bool block=true)
	Reads a single byte from the second port.

void	setDebugState (bool debugState)
	Sets the debug state (blocks IRQs to allow polling).

bool	getDebugState () const
	Gets the debug state.

Public Member Functions inherited from Controller
	Controller (Device *pDev)

virtual Type	getType ()

Public Member Functions inherited from Device
	Device (Device *p)

Device *	getParent () const

void	setParent (Device *p)

virtual String	getSpecificType ()

virtual void	setSpecificType (String str)

void	setPciPosition (uint32_t bus, uint32_t device, uint32_t func)

void	setPciIdentifiers (uint8_t classCode, uint8_t subclassCode, uint16_t vendorId, uint16_t deviceId, uint8_t progIf)

void	setPciConfigHeader (const PciBus::ConfigSpace &space)

PciBus::ConfigSpace	getPciConfigHeader () const

uint8_t	getPciClassCode ()

uint8_t	getPciSubclassCode ()

uint16_t	getPciVendorId ()

uint16_t	getPciDeviceId ()

uint8_t	getPciProgInterface ()

uint32_t	getPciBusPosition ()

uint32_t	getPciDevicePosition ()

uint32_t	getPciFunctionNumber ()

virtual Vector< Address * > &	addresses ()

virtual uintptr_t	getInterruptNumber ()

virtual void	setInterruptNumber (uintptr_t n)

void	addChild (Device *pDevice)

Device *	getChild (size_t n)

size_t	getNumChildren ()

void	removeChild (size_t n)

void	removeChild (Device *d)

void	replaceChild (Device src, Device dest)

Private Member Functions
virtual bool	irq (irq_id_t number, InterruptState &state)

void	waitForReading ()

void	waitForWriting ()

virtual	~IrqHandler ()

Private Attributes
IoBase *	m_pBase

bool	m_bHasSecondPort

Buffer< uint8_t >	m_FirstPortBuffer

Buffer< uint8_t >	m_SecondPortBuffer

bool	m_bFirstIrqEnabled

bool	m_bSecondIrqEnabled

irq_id_t	m_FirstIrqId

irq_id_t	m_SecondIrqId

bool	m_bDebugState

uint8_t	m_ConfigByte

bool	m_bDebugStateFirstIrqEnabled

bool	m_bDebugStateSecondIrqEnabled

Additional Inherited Members
Public Types inherited from Device
enum	Type { Generic, Root, Disk, Bus, Display, Network, Sound, Console, Mouse, Controller, UsbController, UsbGeneric, UsbContainer }

typedef Device (	Callback) (Device *)

Static Public Member Functions inherited from Device
static void	foreach (Callback callback, Device *root=0)

template<class F , class... Args>
static void	foreach (pedigree_std::Callable< F > &callback, Device *root, Args...args)

static void	addToRoot (Device *device)

static void	searchByVendorId (uint16_t vendorId, void(callback)(Device ), Device *root=0)

static void	searchByVendorIdAndDeviceId (uint16_t vendorId, uint16_t deviceId, void(callback)(Device ), Device *root=0)

static void	searchByClass (uint16_t classCode, void(callback)(Device ), Device *root=0)

static void	searchByClassAndSubclass (uint16_t classCode, uint16_t subclassCode, void(callback)(Device ), Device *root=0)

static void	searchByClassSubclassAndProgInterface (uint16_t classCode, uint16_t subclassCode, uint8_t progInterface, void(callback)(Device ), Device *root=0)

Protected Member Functions inherited from Device
	NOT_COPYABLE_OR_ASSIGNABLE (Device)

Static Protected Member Functions inherited from Device
static Device &	root ()

Protected Attributes inherited from Device
Vector< Address * >	m_Addresses

Vector< Device * >	m_Children

Device *	m_pParent

uintptr_t	m_InterruptNumber

String	m_SpecificType

PciBus::ConfigSpace	m_ConfigHeader

uint8_t	m_ClassCode

uint8_t	m_SubclassCode

uint16_t	m_VendorId

uint16_t	m_DeviceId

uint8_t	m_ProgInterface

uint32_t	m_PciBusPos

uint32_t	m_PciDevicePos

uint32_t	m_PciFunctionNum

Static Protected Attributes inherited from Device
static Device	m_Root

static Mutex	m_TreeLock

Detailed Description

Definition at line 34 of file Ps2Controller.h.

Member Function Documentation

virtual void Ps2Controller::dump ( String & str )

inlinevirtual

Dumps a textual representation of the device into the given string.

Reimplemented from Controller.

Definition at line 49 of file Ps2Controller.h.

References EXPORTED_PUBLIC, hasSecondPort(), readByte(), readFirstPort(), readSecondPort(), sendCommand(), sendCommandWithResponse(), setDebugState(), setIrqEnable(), writeFirstPort(), and writeSecondPort().

virtual void Ps2Controller::getName ( String & str )

inlinevirtual

Stores the device's name in str.

Reimplemented from Controller.

Definition at line 44 of file Ps2Controller.h.

bool Ps2Controller::irq	(	irq_id_t	number,
		InterruptState &	state
	)

privatevirtual

Called when the handler is registered with the irq manager and the irq occurred

Note: If this function returns false you have to call IrqManager::acknowledgeIrq() when you removed the interrupt reason.

Parameters

[in] number the irq number

Returns: should return true, if the interrupt reason was removed, or false otherwise

Implements IrqHandler.

Definition at line 285 of file Ps2Controller.cc.

References ERROR, and Hex.

Referenced by getDebugState().

Here is the caller graph for this function:

uint8_t Ps2Controller::sendCommandWithResponse ( uint8_t command )

Send a command to the PS/2 controller and report its response.

Todo:: handle this when we have irqs enabled

Definition at line 123 of file Ps2Controller.cc.

Referenced by dump().

Here is the caller graph for this function:

uint8_t Ps2Controller::sendCommandWithResponse	(	uint8_t	command,
		uint8_t	data
	)

Todo:: handle this when we have irqs enabled

Definition at line 132 of file Ps2Controller.cc.

The documentation for this class was generated from the following files:
