ScsiController Class Referenceabstract

#include <ScsiController.h>

+ Inheritance diagram for ScsiController:
+ Collaboration diagram for ScsiController:

Public Member Functions

 ScsiController (Controller *pDev, bool startWorker=true)

bool prepareDiskRemoval ()

void cancelDiskRemoval ()

virtual bool supportsConcurrentReads () const

virtual bool sendCommand (size_t nUnit, uintptr_t pCommand, uint8_t nCommandSize, uintptr_t pRespBuffer, uint16_t nRespBytes, bool bWrite)=0

virtual uint64_t executeRequest (uint64_t p1, uint64_t p2, uint64_t p3, uint64_t p4, uint64_t p5, uint64_t p6, uint64_t p7, uint64_t p8)

- Public Member Functions inherited from Controller
 Controller (Device *pDev)

virtual Type getType ()

virtual void getName (String &str)

virtual void dump (String &str)

- Public Member Functions inherited from Device
 Device (Device *p)

Device * getParent () const

void setParent (Device *p)

virtual const String & getSpecificType ()

virtual void setSpecificType (String str)

void setPciPosition (uint32_t bus, uint32_t device, uint32_t func)

void setPciIdentifiers (uint8_t classCode, uint8_t subclassCode, uint16_t vendorId, uint16_t deviceId, uint8_t progIf)

void setPciConfigHeader (const PciBus::ConfigSpace &space)

PciBus::ConfigSpace getPciConfigHeader () const

uint8_t getPciClassCode ()

uint8_t getPciSubclassCode ()

uint16_t getPciVendorId ()

uint16_t getPciDeviceId ()

uint8_t getPciProgInterface ()

uint32_t getPciBusPosition ()

uint32_t getPciDevicePosition ()

uint32_t getPciFunctionNumber ()

Device * getPhysicalFunction () const

size_t getVirtualFunctionIndex () const

void setVirtualFunction (Device *physicalFunction, size_t index)

virtual Vector< Address * > & addresses ()

virtual uintptr_t getInterruptNumber ()

virtual void setInterruptNumber (uintptr_t n)

void addChild (Device *pDevice)

Device * getChild (size_t n)

size_t getNumChildren ()

void removeChild (size_t n)

void removeChild (Device *d)

void replaceChild (Device *src, Device *dest)

- Public Member Functions inherited from RequestQueue
 RequestQueue (const String &name)

virtual void initialise ()

virtual void destroy ()

MUST_USE_RESULT uint64_t addRequest (size_t priority, uint64_t p1=0, uint64_t p2=0, uint64_t p3=0, uint64_t p4=0, uint64_t p5=0, uint64_t p6=0, uint64_t p7=0, uint64_t p8=0)

MUST_USE_RESULT uint64_t addRequest (size_t priority, ActionOnDuplicate action, uint64_t p1=0, uint64_t p2=0, uint64_t p3=0, uint64_t p4=0, uint64_t p5=0, uint64_t p6=0, uint64_t p7=0, uint64_t p8=0)

uint64_t addAsyncRequest (size_t priority, uint64_t p1=0, uint64_t p2=0, uint64_t p3=0, uint64_t p4=0, uint64_t p5=0, uint64_t p6=0, uint64_t p7=0, uint64_t p8=0)

MUST_USE_RESULT bool publishAsyncRequest (size_t priority, uint64_t p1=0, uint64_t p2=0, uint64_t p3=0, uint64_t p4=0, uint64_t p5=0, uint64_t p6=0, uint64_t p7=0, uint64_t p8=0)

bool canWaitForCompletion ()

MUST_USE_RESULT bool waitForPreallocated (PreallocatedRequest &request)

MUST_USE_RESULT PreallocatedPublishResult publishPreallocated (PreallocatedRequest &request, size_t priority, uint64_t p1=0, uint64_t p2=0, uint64_t p3=0, uint64_t p4=0, uint64_t p5=0, uint64_t p6=0, uint64_t p7=0, uint64_t p8=0)

MUST_USE_RESULT PreallocatedPublishResult republishPreallocatedWhileReleasing (PreallocatedRequest &request, size_t priority, uint64_t p1=0, uint64_t p2=0, uint64_t p3=0, uint64_t p4=0, uint64_t p5=0, uint64_t p6=0, uint64_t p7=0, uint64_t p8=0)

MUST_USE_RESULT bool halt ()

MUST_USE_RESULT bool resume ()

LifecycleState getLifecycleState ()

bool drain ()


Protected Member Functions

virtual void cancelRequest (const Request &request)

void shutdownDiskCaches (bool deviceAvailable=true)

virtual size_t getNumUnits ()=0

void searchDisks ()

- Protected Member Functions inherited from Device
 NOT_COPYABLE_OR_ASSIGNABLE (Device)

- Protected Member Functions inherited from RequestQueue
virtual bool workerPlacement (ThreadPlacement &) const

 RequestQueue (const RequestQueue &)

void operator= (const RequestQueue &)

virtual bool compareRequests (const Request &a, const Request &b)

int work ()

NextRequestResult getNextRequest (Request *&request)

bool drainIntakeLocked (size_t priority)

void publishRequest (Request *request)

Request * findDuplicate (const Request &request)

void discardRequest (Request *request)

uint64_t addAsyncRequestInternal (size_t priority, uint64_t p1, uint64_t p2, uint64_t p3, uint64_t p4, uint64_t p5, uint64_t p6, uint64_t p7, uint64_t p8)

PreallocatedPublishResult publishPreallocatedRequest (PreallocatedRequest &request, PreallocatedRequest::State availableState, size_t priority, uint64_t p1, uint64_t p2, uint64_t p3, uint64_t p4, uint64_t p5, uint64_t p6, uint64_t p7, uint64_t p8)

void releasePreallocatedRequest (Request *request)

void invokeCancelRequest (const Request &request)

bool callbackActiveOnCurrentThread () const

void releaseRequest (Request *request)

uint64_t waitForRequest (Request *request)

bool startWorker ()

bool stopWorker ()

void closePreallocatedAdmission ()

void waitForPreallocatedPublishers ()


Private Member Functions

bool acquireDiskOperation (OperationBarrier::Lease &operation)


Private Attributes

OperationBarrier m_DiskOperations


Friends

class ScsiDisk


Additional Inherited Members

- Public Types inherited from Device
enum  Type {
  Generic , Root , Disk , Bus ,
  Display , Network , Sound , Console ,
  Mouse , Controller , UsbController , UsbGeneric ,
  UsbContainer
}

typedef Device *(* Callback) (Device *)

- Public Types inherited from RequestQueue
enum class  OverrunStatus { Clear , Armed , Stalled , Overloaded }

enum class  PreallocatedPublishResult {
  Accepted , TokenBusy , QueueStopped , QueueFull ,
  InvalidPriority
}

enum  ActionOnDuplicate { Block , NewRequest , ReturnImmediately }

enum class  LifecycleState { Stopped , Accepting , Stopping , Destroyed }

- Static Public Member Functions inherited from Device
static bool treeLockHeldByCurrentThread ()

static void foreach (Callback callback, Device *root=0)

template<class F , class... Args>
static void foreach (pedigree_std::Callable< F > &callback, Device *root, Args... args)

static void addToRoot (Device *device)

static void searchByVendorId (uint16_t vendorId, void(*callback)(Device *), Device *root=0)

static void searchByVendorIdAndDeviceId (uint16_t vendorId, uint16_t deviceId, void(*callback)(Device *), Device *root=0)

static void searchByClass (uint16_t classCode, void(*callback)(Device *), Device *root=0)

static void searchByClassAndSubclass (uint16_t classCode, uint16_t subclassCode, void(*callback)(Device *), Device *root=0)

static void searchByClassSubclassAndProgInterface (uint16_t classCode, uint16_t subclassCode, uint8_t progInterface, void(*callback)(Device *), Device *root=0)

- Protected Types inherited from RequestQueue
enum class  NextRequestResult { Item , Empty , Retry }

- Static Protected Member Functions inherited from Device
static Device & root ()

- Static Protected Member Functions inherited from RequestQueue
static int trampoline (void *p)

static void completeRequest (Request *request, uint64_t returnValue, bool rejected)

static void retainRequest (Request *request)

- Protected Attributes inherited from Device
Vector< Address * > m_Addresses

Vector< Device * > m_Children

Device * m_pParent

Device * m_PhysicalFunction

size_t m_VirtualFunctionIndex

uintptr_t m_InterruptNumber

String m_SpecificType

PciBus::ConfigSpace m_ConfigHeader

uint8_t m_ClassCode

uint8_t m_SubclassCode

uint16_t m_VendorId

uint16_t m_DeviceId

uint8_t m_ProgInterface

uint32_t m_PciBusPos

uint32_t m_PciDevicePos

uint32_t m_PciFunctionNum

- Protected Attributes inherited from RequestQueue
IntakeLane m_IntakeLanes [REQUEST_QUEUE_NUM_PRIORITIES]

Request * m_pRequestQueue [REQUEST_QUEUE_NUM_PRIORITIES]

Request * m_pRequestQueueTail [REQUEST_QUEUE_NUM_PRIORITIES]

Request * m_pActiveRequest

Atomic< size_t > m_State

Mutex m_LifecycleMutex

WaitQueue m_RequestQueueWaiters

WaitQueue m_WorkerWaiters

Thread * m_pThread

Atomic< PerProcessorScheduler * > m_pWorkerScheduler

SchedulerWorkerWake m_WorkerWake

Atomic< size_t > m_bWorkerReady

Atomic< size_t > m_bWorkerActive

size_t m_WorkerProgressGeneration

RequestQueueOverrunChecker m_OverrunChecker

Timer * m_pOverrunTimer

Atomic< size_t > m_PublicationState

size_t m_nMaxAsyncRequests

Atomic< size_t > m_nAsyncRequests

Atomic< size_t > m_nTotalRequests

Atomic< size_t > m_nActiveRequests

NormalStaticString m_Name

- Static Protected Attributes inherited from Device
static Device m_Root

static Mutex m_TreeLock

- Static Protected Attributes inherited from RequestQueue
static constexpr size_t PublicationClosed = static_cast<size_t>(1) << ((sizeof(size_t) * 8) - 1)

static constexpr size_t PublicationCountMask = ~PublicationClosed


Detailed Description

Generic class for Scsi Controllers

Definition at line 38 of file ScsiController.h.

Constructor & Destructor Documentation

◆ ScsiController() [1/2]

ScsiController::ScsiController ( Controller *  pDev,
bool  startWorker = true
)

Definition at line 28 of file ScsiController.cc.

◆ ScsiController() [2/2]

ScsiController::ScsiController ( )

Definition at line 34 of file ScsiController.cc.

◆ ~ScsiController()

ScsiController::~ScsiController ( )
virtual

Definition at line 39 of file ScsiController.cc.

Member Function Documentation

◆ acquireDiskOperation()

bool ScsiController::acquireDiskOperation ( OperationBarrier::Lease &  operation)
private

Definition at line 46 of file ScsiController.cc.

◆ cancelDiskRemoval()

void ScsiController::cancelDiskRemoval ( )

Definition at line 143 of file ScsiController.cc.

◆ cancelRequest()

void ScsiController::cancelRequest ( const Request &  request)
protectedvirtual

Releases payload ownership for a request that will not execute.

This runs without the queue guard for rejected candidates (including stopped queues, duplicates and capacity limits) and queued requests cancelled by destroy(). Implementations used by allocation-free producers must not sleep. Derived destructors must call destroy() while their override and member state are still alive. During destroy(), the lifecycle is serialized: halt() and resume() on this queue return false, while recursive destroy() is a fatal contract violation.

Reimplemented from RequestQueue.

Definition at line 113 of file ScsiController.cc.

References ScsiDisk::unpin().

◆ executeRequest()

uint64_t ScsiController::executeRequest ( uint64_t  p1,
uint64_t  p2,
uint64_t  p3,
uint64_t  p4,
uint64_t  p5,
uint64_t  p6,
uint64_t  p7,
uint64_t  p8
)
virtual

Callback - classes are expected to inherit and override this function. It's called when a request needs to be executed (by the worker thread).

Implements RequestQueue.

Reimplemented in IsaAtaController, and PciAtaController.

Definition at line 89 of file ScsiController.cc.

References ScsiDisk::doRead(), ScsiDisk::doWriteDirect(), and ScsiDisk::unpin().

◆ prepareDiskRemoval()

bool ScsiController::prepareDiskRemoval ( )

Definition at line 123 of file ScsiController.cc.

◆ searchDisks()

void ScsiController::searchDisks ( )
protected

Definition at line 79 of file ScsiController.cc.

◆ shutdownDiskCaches()

void ScsiController::shutdownDiskCaches ( bool  deviceAvailable = true)
protected

Drains disk work and retires child Cache callbacks. Removed devices discard software cache data and cannot provide a final hardware flush.

Definition at line 50 of file ScsiController.cc.

References OperationBarrier::closeAndWait(), RequestQueue::drain(), Device::getChild(), Device::getNumChildren(), m_DiskOperations, and panic().

Referenced by UsbMassStorageDevice::prepareForDisconnection(), IsaAtaController::shutdown(), and PciAtaController::shutdown().

+ Here is the caller graph for this function:

◆ supportsConcurrentReads()

virtual bool ScsiController::supportsConcurrentReads ( ) const
inlinevirtual

Concurrent cache fills require independent transport command storage.

Reimplemented in AhciController, and NvmeController.

Definition at line 48 of file ScsiController.h.

Friends And Related Symbol Documentation

◆ ScsiDisk

friend class ScsiDisk
friend

Definition at line 70 of file ScsiController.h.

Member Data Documentation

◆ m_DiskOperations

OperationBarrier ScsiController::m_DiskOperations
private

Rejects new filesystem-facing disk work while teardown drains.

Definition at line 75 of file ScsiController.h.

Referenced by shutdownDiskCaches().

The documentation for this class was generated from the following files:
